Omni-channel Payment

NFC
Payment
Stripe Card
Payment
IC card
Payment
QR Code
Payment

32-bit high performance secure processor

Intuitive user interface

2.4" LCM / 320x240 pixels

Keypad privacy shield provides extra security for your customers to enter their PINs safely

Financial-grade data protection, worriless payment

With multiple certifications of the financial industry, FEITIAN T50 provides
a secure payment environment to the merchants and users

Application Industries

T50 Product Specification
Processor

32-bit RISC Core

Memory

RAM: 1MB / ROM: 4MB

Physical

151.4mm (L) × 80.5mm (W) × 56.1mm (H)

Camera

0.3M pixel front scanner, support 1D/2D code payment

Display

2.4 inch, 240*320, TFT Resistive touchscreen, support electronic signature

Card Slot

PSAM*2

Adapter

5V/500mA

Keys / Buttons

16 Keys: 0 ~ 9 | Enter | Clear | Cancel | Function | Up | Down

Magnetic

Conform to ISO 7810/7811/7813, Track 1/2/3, Bi-directional swiping

IC

EMV L1/L2, Conform to ISO 7816, 1.8V/3V/5V

NFC

Conforming to ISO 14443 Type A/B, Mifare

QR Code
Peripheral Ports

USB

Weight

212g

Environmental

Operating Temperature: -10°C ~ 50°C (14°F~122°F)
Storage Temperature: -20°C ~ 70°C (-4°F~158°F) )
Relative Humidity: 5%-96% (Non-Condensing)

Certifications

PCI, EMV L1&L2, EMV Contactless L1 Paypass, Paywave, AMEX ExpressPay, Discover, Pure, TQM CE, NTRA-VOC, ANRT, WEEE
